BGA160153 - Square D 15 Amp 600 Volt 1 Pole Thermal Magnetic Molded Case Circuit Breaker

BGA160153

BGA160153 is a 15 Amp, 600 Volt, 1 Pole thermal magnetic molded case circuit breaker from Square D designed for reliable circuit protection.This circuit breaker features a thermal magnetic trip unit providing both long-time and instantaneous protection. It is part of the Powerpact family and supports a voltage rating up to 600 VAC with a short circuit interrupting capacity of 35kA at 480V. The breaker is designed for single-phase applications and offers robust protection in a compact form factor.

• Amperage: 15 Amps
• Voltage Rating: 600 VAC
• Poles: 1
• Trip Unit: Thermal Magnetic
• Interrupt Rating: 35kA at 480V
• Series/Frame: Powerpact
• Phase: Single
• Mounting Type: Molded Case

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BGA160153
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BGA
• Voltage : 600
• Amperage : 15
• Phase : 1
• Poles : 1
• AIC rating : 65kA@240V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Frame Size : B Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 060648115326
• GTIN : 03606481153265
• Country of Origin : Mexico
• Dimensions : 5.4 in (137 mm) x 1.06 in (27 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 1.696
• Standards : EN/IEC 60947-5-1, GB 14048.2, NMX J-266, NEMA AB1, CSA C22.2 No 5, UL 489, EN/IEC 60947-2
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
