Product Description & Specifications
Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.
- Manufacturer
- Schneider Electric
- Sub-Category
- Molded Case
- Rated current
- 20
- Voltage
- 600V
- Poles
- 3
- Phases
- 3
- Interrupting rating
- 18kA@480V
- Trip functions
- Long Time and Instantaneous Trip
- Protection
- Thermal Magnetic
- Connection
- Feed-Thru
- Terminals
- Everlink Lug Both Ends
- Phase connection
- ABC
- Panel / equipment
- Electrical Distribution Equipment, Industrial Control Panels
- Mounting
- Unit Mount
- Standards
- NEMA AB1, GB 14048.2, NMX J-266, UL 489, CSA C22.2 No 5, EN/IEC 60947-5-1, EN/IEC 60947-2
- Country of origin
- Mexico
Show all specifications (10 more)
- Frame Size
- 125A/BD
- Temp Rating
- -13°F to 158°F (-25°C to 70°C)
- MCM Size
- Min. Wire Size 14 AWG, 6 AWG Max. Wire Size 2 AWG, 3 AWG
- Breaker Type
- Standard
- UPC
- 785901094333
- GTIN
- 03606481149060
- Dimensions
- 5.4 in (137 mm) x 3.2 in (81 mm) x 3.1 in (80 mm) (Height x Width x Depth)
- Weight
- 2.599
- Certification
- UL, IEC, CCC, EAC, CSA, NOM
- Wire Size
- AWG 6...AWG 2/0 fine stranded aluminium/copper AWG 14...AWG 3/0 rigid or stranded aluminium/copper
Product description & additional details
BDL36020LU
BDL36020LU is a Schneider Electric PowerPact B molded case circuit breaker designed for reliable thermal magnetic protection in industrial and commercial applications.BDL36020LU features a 20 Amp current rating, 3 poles, and a voltage rating of 600Y/347VAC. It offers a breaking capacity of 14kA at 600Y/347VAC and includes lug connections for easy installation. This breaker is dual rated for AC/DC and complies with UL 489, CSA, NOM, IEC 60947-2, CCC, and CE certifications.
- Key Specifications
- Amperage: 20 Amps
- Voltage Rating: 600Y/347VAC
- Poles: 3
- Interrupt Rating: 14kA at 600Y/347VAC
- Mounting Type: Unit Mount
- Trip Unit: Thermal Magnetic
- Series/Frame: PowerPact B
- Certifications: UL 489, CSA, NOM, IEC 60947-2, CCC, CE
- Control Wire On End: 80%
- Environmental: Recyclable packaging, carbon footprint 129 kg CO2 eq
Specifications
- Part Number: BDL36020LU
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 600
- Amperage : 20
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Terminal Connection : Everlink Lug Both Ends
- Frame Size : 125A/BD
- Temp Rating : -13°F to 158°F (-25°C to 70°C)
- MCM Size : Min. Wire Size 14 AWG, 6 AWG Max. Wire Size 2 AWG, 3 AWG
- Breaker Type : Standard
- Circuit Breaker Mounting Style : Unit Mount
- Protection : Thermal Magnetic
- Phase Connection : ABC
Product Data
- UPC : 785901094333
- GTIN : 03606481149060
- Country of Origin : Mexico
- Dimensions : 5.4 in (137 mm) x 3.2 in (81 mm) x 3.1 in (80 mm) (Height x Width x Depth)
- Weight : 2.599
- Panel Type : Electrical Distribution Equipment, Industrial Control Panels
- Standards : NEMA AB1, GB 14048.2, NMX J-266, UL 489, CSA C22.2 No 5, EN/IEC 60947-5-1, EN/IEC 60947-2
- Certification : UL, IEC, CCC, EAC, CSA, NOM
- Wire Size : AWG 6...AWG 2/0 fine stranded aluminium/copper
AWG 14...AWG 3/0 rigid or stranded aluminium/copper
