Product Description & Specifications
Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.
- Manufacturer
- Schneider Electric
- Sub-Category
- Molded Case
- Series
- PowerPact B
- Rated current
- 15
- Voltage
- 600V
- Poles
- 3
- Phases
- 3
- Interrupting rating
- 18kA@480V
- Protection
- Thermal Magnetic
- Connection
- Feed-Thru
- Terminals
- Everlink Lug Both Ends
- Phase connection
- ABC
- Panel / equipment
- Electrical Distribution Equipment, Industrial Control Panels
- Standards
- CSA C22.2 No 5, NEMA AB1, EN/IEC 60947-5-1, GB 14048.2, UL 489, EN/IEC 60947-2, NMX J-266
- Country of origin
- Mexico
Show all specifications (10 more)
- Frame Size
- 125A/BD
- Temp Rating
- -13°F to 158°F (-25°C to 70°C)
- MCM Size
- Min. Wire Size 14 AWG, 6 AWG Max. Wire Size 2 AWG, 3 AWG
- Breaker Type
- Standard
- UPC
- 785901094289
- GTIN
- 03606481149053
- Dimensions
- 5.4 in (137 mm) x 3.2 in (81 mm) x 3.1 in (80 mm) (Height x Width x Depth)
- Weight
- 2.599
- Certification
- UL, IEC, CCC, EAC, CSA, NOM
- Wire Size
- AWG 6...AWG 2/0 fine stranded aluminium/copper AWG 14...AWG 3/0 rigid or stranded aluminium/copper
Product description & additional details
BDL36015LU
BDL36015LU is a PowerPacT B molded case circuit breaker manufactured by Schneider Electric, designed for three-phase power distribution and protection in industrial and commercial applications.
This thermal magnetic circuit breaker features a 15 amp continuous current rating with an 80% duty cycle and a 14kA breaking capacity at 600Y/347VAC. The unit is equipped with lugs for direct connection and includes control wire ON end configuration. The toggle actuator provides reliable manual operation and status indication.
- Current Rating: 15 Amps
- Number of Poles: 3
- Voltage Rating: 600Y/347VAC
- Breaking Capacity: 14kA at 600Y/347VAC
- Trip Unit: Thermal Magnetic
- Continuous Current Rating: 80%
- Actuator Type: Toggle
- Connection Type: Lugs
- Series: PowerPacT B
- Control Wire: ON end
- Rated Insulation Voltage: 800V IEC 60947-2
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: BDL36015LU
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : PowerPact B
- Voltage : 600
- Amperage : 15
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Terminal Connection : Everlink Lug Both Ends
- Frame Size : 125A/BD
- Temp Rating : -13°F to 158°F (-25°C to 70°C)
- MCM Size : Min. Wire Size 14 AWG, 6 AWG Max. Wire Size 2 AWG, 3 AWG
- Breaker Type : Standard
- Protection : Thermal Magnetic
- Phase Connection : ABC
Product Data
- UPC : 785901094289
- GTIN : 03606481149053
- Country of Origin : Mexico
- Dimensions : 5.4 in (137 mm) x 3.2 in (81 mm) x 3.1 in (80 mm) (Height x Width x Depth)
- Weight : 2.599
- Panel Type : Electrical Distribution Equipment, Industrial Control Panels
- Standards : CSA C22.2 No 5, NEMA AB1, EN/IEC 60947-5-1, GB 14048.2, UL 489, EN/IEC 60947-2, NMX J-266
- Certification : UL, IEC, CCC, EAC, CSA, NOM
- Wire Size : AWG 6...AWG 2/0 fine stranded aluminium/copper
AWG 14...AWG 3/0 rigid or stranded aluminium/copper
