BDA160605 - Schneider Electric 60A 1 Pole 600Y/347V AC PowerPact B Circuit Breaker Thermal Magnetic

BDA160605

BDA160605 is a Schneider Electric PowerPact B circuit breaker designed for reliable circuit protection with a 60 ampere rating and 1 pole configuration.

This thermal magnetic breaker supports a voltage rating of 600Y/347V AC and features an interrupting capacity of 14kA at 600Y/347V. It is designed for I-Line plug-in mounting and accepts AWG 14 to AWG 2/0 aluminum or copper conductors. The breaker includes line and load lugs and a green auxiliary contact flag for status indication.

• Amperage: 60A
• Voltage Rating: 600Y/347V AC
• Poles: 1
• Mounting Type: I-Line plug-in
• Interrupt Rating: 14kA at 600Y/347V
• Breaker Type: Thermal Magnetic
• Conductor Size: AWG 14 to AWG 2/0 aluminum/copper
• Auxiliary Contact: Green flag indicator
• Series/Frame: PowerPact B

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BDA160605
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BDA
• Voltage : 600
• Amperage : 60
• Phase : 1
• Poles : 1
• AIC rating : 25kA@240V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : B Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 060648115138
• GTIN : 03606481151384
• Dimensions : 5.4 in (137 mm) x 1.06 in (27 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 2.2
• Standards : UL 489, EN/IEC 60947-2, NEMA AB1, EN/IEC 60947-5-1, CSA C22.2 No 5, GB 14048.2, NMX J-266
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
