Product Info
- Manufacturer:Siemens
- Sub-Category:Motor Starter
Description
3RV1021-1JA10
3RV1021-1JA10 is a Siemens motor protector circuit breaker with adjustable thermal overload release settings from 7 to 10 amps and Class 10 trip characteristics.
This device features a rotary ON/OFF dial for motor full load amperage (FLA) adjustment, built-in heater elements for overload protection, and magnetic trip elements to protect motors from short circuits. It is designed for DIN rail mounting and belongs to the Frame Size S0 series, suitable for motor protection applications up to 4 kW with operating voltages from 220 to 690 VAC. The unit uses screw terminals and offers a standard switching capacity with a nominal release current of 7-10 A and a short-circuit release rating of 130 A.
- Key Specifications
- Adjustable current setting range: 7 to 10 Amps
- Class 10 overload trip unit
- Frame size: S0
- Mounting type: DIN rail
- Operating voltage: 220-690 VAC
- Maximum motor power: 4 kW
- Screw terminal connection
- Standard switching capacity
- Short-circuit release rating: 130 A
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 3RV1021-1JA10
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Motor Starter
- Family : 3RV1
- Type : 3RV10
- Amperage : 10
- Nema Rating : 0
Product Data
- UPC : 754554409269
- GTIN : 04011209281189
- Weight : 1
