Product Info
- Manufacturer:Siemens
- Sub-Category:Motor Starter
Description
3RV1021-0AA10
3RV1021-0AA10 is a Siemens SIRIUS 3RV10 motor protection circuit breaker designed for reliable motor control and overload protection in industrial applications. This device features a manual ON/OFF rotary handle with lockout and visible trip indication, an adjustable dial for setting motor full load amps, and Class 10 overload trip characteristics. It provides both overload and short-circuit protection, with a short-circuit trip at 12 times the maximum setting of the FLA adjustment dial. The unit is ambient compensated up to 140°F and offers phase loss sensitivity for enhanced motor protection.
- Adjustable current range: 0.11 to 0.16 A
- Rated voltage: 690 VAC
- Number of poles: 3
- Interrupt rating: 100 kA
- Frame/series: S0
- Mounting type: Screw terminal
- Overload trip class: Class 10
- Short-circuit trip: 2.1 A
- Enclosure rating: IP20
- Complies with IEC 60947-4-1
- UL508 Type E self-protected manual combination starter
- Lockable in OFF position
Specifications
- Part Number: 3RV1021-0AA10
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Motor Starter
- Family : 3RV1
- Type : 3RV10
- Amperage : 18
- Nema Rating : 0
Product Data
- GTIN : 04011209297463
- Weight : 0.638
