Product Description & Specifications
Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.
- Manufacturer
- ABB
- Sub-Category
- Molded Case
- Series
- SACE Tmax XT
- Frame
- XT1SU
- Rated current
- 15
- Voltage
- 600V
- Poles
- 3
- Phases
- 3
- Interrupting rating
- 35kA@480V
- Trip functions
- Long Time and Instantaneous Trip
- Protection
- Thermal Magnetic
- Connection
- Bolt-On
- Frequency
- 50/60 Hz
- Standards
- UL, CSA
- Country of origin
- United States
Show all specifications (2 more)
- Weight
- 5
- Certification
- UL, CSA
Product description & additional details
XT1SU3015AFF000XXX
XT1SU3015AFF000XXX is an ABB Tmax XT series molded case circuit breaker rated at 15A with 3 poles and thermal magnetic trip protection.This XT1 frame breaker provides reliable low voltage protection with 600Y/347 VAC rating, 22 kA interrupt capacity at 480V, and fixed thermal/fixed magnetic trip unit. It features front line/load side connection without lugs, double insulated design, and operates in temperatures from -13 to 158 deg F. The compact dimensions are 5.12 in H x 3 in W x 2.75 in D, suitable for DIN rail or back plate mounting in switchboards.
- Part Number: XT1SU3015AFF000XXX
- Manufacturer: ABB
- Series: Tmax XT
- Frame Size: XT1 125A
- Amperage Rating: 15 A
- Voltage Rating: 600Y/347 VAC
- Number of Poles: 3
- Trip Unit: Thermal Magnetic Fixed
- Interrupt Rating: 22 kA
- Frequency: 50/60 Hz
- Mounting: Fixed, Front Terminals
Specifications
- Part Number: XT1SU3015AFF000XXX
- Manufacturer : ABB
- Brand : ABB
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : SACE Tmax XT
- Type : XT1SU
- Voltage : 600
- Amperage : 15
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Protection : Thermal Magnetic
Product Data
- Country of Origin : United States
- Weight : 5
- Standards : UL, CSA
- Certification : UL, CSA
