Eaton

PDG3XTFA30150

Eaton 150A 600V 3 Pole Power Defense Trip Unit Frame J-K

Current: 150Poles: 3Voltage: 600VAC
Choose your condition
Compare New & Re-Certified

New
Original equipment manufacturer (OEM) products that have never been energized. New items may come in their original factory packaging or may be unused components removed from new panels. Packaging and cosmetic appearance can vary; contact our team for details or photos of the available unit.

Re-Certified
Original equipment manufacturer (OEM) products that have previously been energized and have been inspected, tested, and recertified for return to service. These items may show signs of prior use. Contact our team for details about the unit’s condition, testing documentation, and applicable warranty.

Ask about this part →
$538.81
Low inventory, please call (866) 377-3532 for stock check
View warranty coverage Return eligibility

Need it urgently? Call to confirm shipping options

Buying for a project? Request a quote

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

Product Description & Specifications

Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.

Manufacturer
Eaton
Sub-Category
Trip Units & Programmers
Series
Power Defense Series
Frame
PDG
Rated current
150
Max current rating
150
Voltage
600VAC
Poles
3
Trip functions
Long Time and Instantaneous Trip
Protection
Thermal Magnetic
Terminals
Standard Line and Load Side Lug
Standards
RoHS
Temp Rating
-13°F to 158°F (-25°C to 70°C)
Amperage Maximum
150
Show all specifications (6 more)
Compatible Frames
PDG
UPC
786679588918
GTIN
00786679588918
Dimensions
8.31 in x 4.18 in x 5.18 in (Length/Depth x Height x Width)
Weight
2.1
Certification
IEC, CSA, UL, CCC
Product description & additional details

PDG3XTFA30150


PDG3XTFA30150 is a 150 Amp, 600 Volt, 3 Pole Power Defense trip unit from Eaton designed for use with PD3 Global circuit breakers in Frame J-K.This Eaton Power Defense trip unit provides reliable circuit protection with a 150 Amp current rating and a maximum voltage of 600 VAC. It is compatible with PD3 Global circuit breakers and fits Frame J-K sizes, offering robust performance for industrial and commercial electrical distribution applications.
    Key Specifications
    • Amperage Rating: 150 A
    • Voltage Rating: 600 V AC
    • Poles: 3
    • Circuit Breaker Type: PD3 Global
    • Frame Size: Frame J-K
    • Series: Power Defense
    • Mounting Type: Globally Rated
    At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

    Specifications

    • Part Number: PDG3XTFA30150
    • Manufacturer : Eaton
    • Brand : Eaton
    • Category : Circuit Breaker
    • Item Subcategory : Trip Units & Programmers
    • Family : Power Defense Series
    • Type : PDG
    • Voltage : 600VAC
    • Amperage : 150
    • Poles : 3
    • Functions : Long Time and Instantaneous Trip
    • Terminal Connection : Standard Line and Load Side Lug
    • Temp Rating : -13°F to 158°F (-25°C to 70°C)
    • Amperage Maximum : 150
    • Protection : Thermal Magnetic
    • Compatible Frames : PDG

    Product Data

    • UPC : 786679588918
    • GTIN : 00786679588918
    • Dimensions : 8.31 in x 4.18 in x 5.18 in (Length/Depth x Height x Width)
    • Weight : 2.1
    • Standards : RoHS
    • Certification : IEC, CSA, UL, CCC
