MJP36450YP - Schneider Electric PowerPact M Circuit Breaker 450A 3 Pole 600VAC Electronic Trip Unit I-Line

MJP36450YP

MJP36450YP is a Schneider Electric PowerPact M circuit breaker rated for 450 amps, 3 poles, and 600 volts AC with an electronic trip unit and I-Line mounting style. This circuit breaker features a 25 kA interrupt rating at 600 VAC, an 80% standard rating, and is designed for plug-in I-Line installation. It includes an electronic trip unit (ET 1.0) that provides optimized protection for overload and short circuit conditions. The breaker is UL 489, CSA, NMX, and IEC certified, ensuring compliance with major safety standards. It has common mounting holes, handle locations, and trim dimensions for easy integration into existing systems.

• Amperage: 450 A
• Voltage: 600 V AC
• Poles: 3
• Interrupt Rating: 25 kA at 600 VAC
• Mounting Type: I-Line plug-in
• Trip Unit: Electronic, ET 1.0
• Frame/Series: PowerPact M
• Standard Rating: 80%
• Certifications: UL 489, CSA, NMX, IEC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: MJP36450YP
• Manufacturer : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : MJP
• Voltage : 600
• Amperage : 450
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : M Frame
• Protection : Solid State

Product Data

• Weight : 34
