Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MJP36400
MJP36400 is a Schneider Electric PowerPact M series molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This 3-pole, 400 amp breaker operates at 600 volts and features a high interrupt rating for demanding applications.Engineered for durability and safety, the MJP36400 breaker provides solid-state protection and is suitable for bolt-on mounting. It is part of the PowerPact M series, known for robust performance and compatibility with a wide range of electrical panels.
- 400A amperage rating
- 600V maximum voltage
- 3 poles
- Bolt-on mounting
- 65kA interrupt rating @ 480V
- PowerPact M series
- Solid-state trip unit
- UL 489 Listed
- CSA certified
- IEC certified
Specifications
- Part Number: MJP36400
- Manufacturer : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : MJP
- Voltage : 600
- Amperage : 400
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : M Frame
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Solid State
Product Data
- Dimensions : Height 12.86 in (326.64 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 34
- Wire Size : 3 x AWG 3/0...3 x 500 kcmil aluminum/copper
