LGM36600U31X - Square D PowerPact L 600A 3P 600VAC 18kAIC Molded Case Circuit Breaker with Micrologic 3.3 Trip Unit, Lug Terminals, UL 489 Listed

LGM36600U31X

LGM36600U31X is a Square D PowerPact L series molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems.

This 3-pole circuit breaker features a 600A amperage rating, 600VAC voltage rating, and an 18kA interrupting capacity. It is equipped with a Micrologic 3.3 electronic trip unit for precise overload and short-circuit protection, and comes with lug terminals for secure electrical connections. The breaker is panel mount type and is certified to UL 489, CSA, NEMA, NMX, VDE, BS, CCC, IEC, and CE standards for global compliance and safety.

Key Specifications
• Amperage: 600A
• Voltage: 600VAC
• Poles: 3
• Mounting Type: Panel Mount
• Interrupt Rating: 18kAIC at 600VAC
• Series/Frame: PowerPact L
• Trip Unit: Micrologic 3.3 (Electronic)
• Terminal Type: Lugs
• Certifications: UL 489 Listed, CSA, NEMA, NMX, VDE, BS, CCC, IEC, CE
• Protection: Overload and short circuit
• Application: Main panel disconnect for control panels
• Environmental: Packaging made with recycled cardboard

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LGM36600U31X
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 600
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Solid State

Product Data

• GTIN : 00786685442907
• Country of Origin : United States
• Dimensions : 13.4 in (340 mm) x 5.5 in (140 mm) x 4.3 in (110 mm) (Height x Width x Depth)
• Weight : 15
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 2 x AWG 2/0...500 kcmil aluminium/copper
