Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
LAL26300MB
LAL26300MB is a Square D 2-pole thermal magnetic molded case circuit breaker rated for 300 amps and 600 volts AC. LAL26300MB provides reliable protection against overloads and short circuits in electrical distribution systems. It features a thermal magnetic trip unit with an interrupt rating of 22kA at 600VAC and 10kA at 250VDC. The breaker has a compact design with a shorter handle (MB suffix) and fits the LAL frame series.
- Amperage: 300 Amps
- Voltage Rating: 600VAC, 250VDC
- Poles: 2
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 22kA @ 600VAC, 10kA @ 250VDC
- Frame Type: LAL
- Mounting Type: Molded Case
- Handle Type: Short Handle (MB suffix)
- Certifications: UL Listed
Specifications
- Part Number: LAL26300MB
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LAL Series
- Type : LAL
- Voltage : 600
- Amperage : 300
- Phase : 1
- Poles : 2
- AIC rating : 30kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Terminal Connection : Lug
- Protection : Thermal Magnetic
Product Data
- UPC : 785901205142
- GTIN : 00785901205142
- Country of Origin : Mexico
- Dimensions : 11 in (279.4 mm) x 6 in (152.4 mm) x 5.84 in (148.34 mm) (Height x Width x Depth)
- Weight : 14.275
- Standards : CSA, UL Listed, IEC
- Certification : CSA, UL Listed, IEC
- Wire Size : AWG 1 to 250/600KCmil Copper/Aluminum
