JLF36175 - Square D 175A 3-Pole 600VAC Powerpact J Frame Circuit Breaker Thermal Magnetic 50kA

JLF36175

JLF36175 is a Square D Powerpact J Frame molded case circuit breaker rated for 175 amps and 600 volts AC with a 3-pole configuration.

This circuit breaker features thermal-magnetic trip technology with an 80% continuous current rating and a 50kA interrupting capacity at 600VAC. It is designed for busbar mounting and unit mount lug connections, providing reliable overload and short-circuit protection. The breaker is UL listed and suitable for industrial and commercial electrical distribution applications.

• Manufacturer: Square D
• Part Number: JLF36175
• Amperage: 175A
• Voltage Rating: 600VAC
• Poles: 3
• Frame Type: Powerpact J Frame
• Interrupt Rating: 50kA at 600VAC
• Trip Unit: Thermal Magnetic
• Mounting Type: Busbar, Unit Mount Lug
• Continuous Current Rating: 80%
• UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JLF36175
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JLF
• Voltage : 600
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 606486283489
• GTIN : 03606486283486
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 4...AWG 4/0 aluminium/copper terminal
