JDP26200 - Square D PowerPact J Frame 200A 2-Pole 600V Molded Case Circuit Breaker

JDP26200

JDP26200 is a Square D PowerPact J Frame molded case circuit breaker designed for reliable protection in commercial and industrial applications. This 2-pole, 200 amp breaker is rated for up to 600 volts AC and features a thermal magnetic trip unit for precise overcurrent protection. The unit mount design allows for easy installation in compatible panels and switchgear. The JDP26200 is built to meet UL 489 standards and offers current limiting and adjustable trip capabilities. It is suitable for use in a wide range of electrical distribution systems, providing dependable performance and safety. The breaker is constructed for durability and long service life in demanding environments.

• Part Number: JDP26200
• Manufacturer: Square D
• Series/Frame: PowerPact J Frame
• Amperage Rating: 200A
• Voltage Rating: 600V AC
• Poles: 2
• Mounting Type: Unit Mount
• Interrupt Rating: 18kA @ 480V AC
• Interrupt Rating: 14kA @ 600V AC
• Interrupt Rating: 25kA @ 240V AC
• Trip Unit: Thermal Magnetic
• Certification: UL 489 Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JDP26200
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JDP
• Voltage : 600
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901582946
• GTIN : 00785901582946
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.699
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
