JDA262502 - Square D 250 Amp 600 VAC 2-Pole PowerPact J-Frame I-Line Circuit Breaker

JDA262502

JDA262502 is a Square D PowerPact J-Frame molded case circuit breaker designed for reliable overcurrent protection in industrial and commercial applications.JDA262502 features a 250 Amp rating, 2 poles, and supports up to 600 VAC with a 14 kA interrupting rating at 600 VAC. It uses an I-Line plug-in mounting system and incorporates thermal-magnetic trip units with long time and instantaneous trip functions for precise protection. This breaker is UL, CSA, CE, IEC, and NEMA certified, suitable for use in power distribution panels and switchboards.

Key Specifications
• Amperage: 250 Amp
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 2
• Mounting Type: I-Line plug-in
• Interrupting Rating: 14 kA at 600 VAC
• Frame Type: PowerPact J-Frame
• Trip Unit: Thermal-magnetic with long time and instantaneous trip
• Certifications: UL, CSA, CE, IEC, NEMA
• Terminal Connection: Line and load side lug
• Wire Gauge Compatibility: AWG 3/0 to 350 kcmil, aluminum/copper
• Operating Temperature Range: -2 to 70 °C
• Application: Industrial, commercial power distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JDA262502
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JDA
• Voltage : 600
• Amperage : 250
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : I-Line, Lug
• Frame Size : D
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 3/0 AWG (Cu/Al) Max. Wire Size 350 kcmil (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : AC

Product Data

• UPC : 785901912262
• GTIN : 00785901912262
• Country of Origin : Mexico
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
