Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HLD3350X
HLD3350X is an Eaton Series C complete molded case circuit breaker designed for industrial power distribution and motor protection applications. This L-frame breaker features fixed thermal and fixed magnetic trip units with aluminum line and load terminals, operating at 50/60 Hz for reliable performance in demanding environments. Key Specifications
- Amperage Rating: 350 A
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: Three-pole
- Circuit Breaker Type: HLD
- Frame Size: L-frame
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
- Terminal Configuration: Line and load
- Terminal Material: Aluminum
- Frequency Rating: 50 to 60 Hz
- Certifications: UL Listed
- Dimensions: 8.25 in H x 8.25 in W x 4.06 in D
- Weight: 21 lb
Specifications
- Part Number: HLD3350X
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HLD
- Voltage : 600
- Amperage : 350
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 22
