Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HLD3300X
HLD3300X is a 300 Amp, 600 Volt, 3 Pole molded case circuit breaker from Eaton's Series C L-frame lineup.This Eaton HLD3300X circuit breaker features a fixed thermal and fixed magnetic trip unit designed for reliable protection in industrial and commercial applications. It supports both line and load connections and is rated for 100 kA interrupting capacity at 240 VAC and 65 kA at 480 VAC. The breaker is suitable for 50/60 Hz systems and can also handle 250 VDC. Its patented contact design provides high-speed blow-open action for superior performance and durability.
- Manufacturer: Eaton
- Part Number: HLD3300X
- Series: Series C L-Frame
- Amperage: 300 Amp
- Voltage Rating: 600 VAC, 250 VDC
- Poles: 3 Pole
- Trip Unit: Fixed Thermal, Fixed Magnetic
- Interrupt Rating: 100 kAIC at 240 VAC, 65 kAIC at 480 VAC
- Mounting Type: Bolt-On
- Frequency: 50/60 Hz
Specifications
- Part Number: HLD3300X
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HLD
- Voltage : 600
- Amperage : 300
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 22
