HLD3300 - Eaton 300 Amp 600 Volt 3 Pole Series C Molded Case Circuit Breaker L Frame Thermal Magnetic Trip

HLD3300

HLD3300 is a 300 Amp, 600 Volt, 3 Pole molded case circuit breaker from Eaton's Series C, L Frame with thermal magnetic trip.HLD3300 features fixed thermal and magnetic trip units, a 65kA interrupt rating at 480 VAC, and 100kA at 240 VAC. It is panel mountable with aluminum line and load terminals, designed for industrial applications requiring reliable circuit protection. UL and CSA certified, this breaker supports 50/60 Hz frequency and is suitable for use up to 250 VDC.

Key Specifications
• Amperage: 300 A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 3
• Interrupt Rating: 65 kA at 480 VAC, 100 kA at 240 VAC
• Frame Type: L Frame
• Trip Unit: Fixed Thermal Magnetic
• Mounting Type: Panel Mount
• Terminals: Aluminum Line and Load
• Series: Series C
• Frequency: 50/60 Hz
• Certifications: UL Listed, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLD3300
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HLD
• Voltage : 600
• Amperage : 300
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Frame Size : L Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679006559
• GTIN : 00786679006559
• Country of Origin : United States
• Dimensions : 8 in x 10 in x 10 in (Length/Depth x Height x Width)
• Weight : 21
• Certification : UL Listed
