Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HLD3350W
HLD3350W is a 350 Amp, 600 Volt, 3-pole molded case circuit breaker from Eaton's Series C L-frame HLD line.This Eaton HLD3350W circuit breaker features fixed thermal and fixed magnetic trip units designed for reliable protection in industrial and commercial electrical systems. It supports both 600 VAC and 250 VDC voltage ratings with a high interrupt rating of 100 kAIC at 240 VAC and 65 kAIC at 480 VAC. The breaker has aluminum line and load terminals and is UL Listed for safety and performance. It is a bolt-on type breaker suitable for 50/60 Hz applications.
- Key Specifications
- Amperage: 350 Amp
- Voltage Rating: 600 VAC, 250 VDC
- Number of Poles: 3
- Frame Type: L-Frame
- Series: Series C
- Trip Unit: Fixed Thermal, Fixed Magnetic
- Interrupt Rating: 100 kAIC at 240 VAC, 65 kAIC at 480 VAC
- Terminal Material: Aluminum
- Mounting Type: Bolt-on
- Frequency: 50/60 Hz
- Certifications: UL Listed
- Part Number: HLD3350W
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HLD
- Voltage : 600
- Amperage : 350
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
- Weight : 22
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
