HLA360606 - Square D PowerPacT H 60A 3-Pole 600VAC Circuit Breaker

HLA360606

HLA360606 is a PowerPacT H-Frame molded case circuit breaker rated for 60 amperes at 600 volts AC with thermal magnetic protection. This 3-pole unit delivers reliable circuit protection for industrial and commercial power distribution applications. HLA360606 features a breaking capacity of 50kA at 600VAC and is designed for unit mount installation in panelboards and switchgear. The thermal magnetic trip mechanism provides coordinated protection against overloads and short circuits.

• Amperage Rating: 60 Amps
• Voltage Rating: 600 VAC
• Poles: 3-Pole
• Frame Type: PowerPacT H-Frame
• Protection Type: Thermal Magnetic
• Breaking Capacity: 50kA at 600VAC
• Mounting: Unit Mount
• UL Listed: UL 489

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLA360606
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HLA
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
