Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
HLA260302
HLA260302 is a Square D molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This breaker features a 2-pole configuration and is rated for 30A at 600V AC, making it suitable for a wide range of applications requiring robust circuit protection. The HLA260302 utilizes thermal-magnetic trip technology for both overload and short-circuit protection, ensuring safe and efficient operation. It is built with an H-Frame design and is specifically engineered for I-Line plug-in mounting, allowing for easy installation and replacement in compatible power distribution panels. This circuit breaker is constructed to meet rigorous safety standards and is suitable for use in environments where high interrupting capacity and dependable performance are essential. The breaker is designed for 1-phase applications and is compatible with I-Line bus systems, providing a secure and efficient connection. Its non-interchangeable trip unit ensures that only the correct replacement parts are used, maintaining system integrity and safety.
- Part Number: HLA260302
- Manufacturer: Square D
- Amperage: 30A
- Voltage: 600V AC
- Poles: 2
- Mounting Type: I-Line Plug-In
- Series/Frame: H-Frame
- Trip Unit: Thermal-Magnetic
- Interrupt Rating: 20kA DC
- Standards: California Proposition 65
Specifications
- Part Number: HLA260302
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : HLA
- Voltage : 600
- Amperage : 30
- Phase : 1
- Poles : 2
- AIC rating : 100kA@480V
- Connection : I-Line Style Plug-In
- Functions : LI - Long-Time and Instantaneous
- Frame Size : H Frame
- Temp Rating : 28-158 °F (-2-70 °C)
- Protection : Thermal Magnetic
Product Data
- GTIN : 03606486282540
- Country of Origin : Mexico
- Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
- Weight : 3.999
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
