HLA260201 - Square D 20A 2-Pole 600V Molded Case Circuit Breaker PowerPact H I-Line

HLA260201

HLA260201 is a Square D 20 amp, 2-pole molded case circuit breaker designed for PowerPact H I-Line applications.This thermal magnetic circuit breaker provides reliable overcurrent protection with a 600 Volt AC rating and a high interrupting capacity. It features a current limiting trip unit suitable for use in Class 611/612 I-Line panelboards and switchboards. The breaker is UL, CSA, and CE certified, ensuring compliance with industry safety standards. It supports both 50/60 Hz AC and 250 V DC applications.

• Amperage: 20 Amps
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 2
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 100kA at 480V
• Series/Frame: PowerPact H
• Trip Unit: Thermal Magnetic, Current Limiting
• Certifications: UL, CSA, CE
• Application: Panelboard and Switchboard
• Frequency: 50/60 Hz

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLA260201
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901553366
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
