HJL36100M73SK - Square D 100A 600V 3 Pole H-Frame Thermal Magnetic Circuit Breaker 65kA@480V

HJL36100M73SK

HJL36100M73SK is a Square D Powerpact H-Frame molded case circuit breaker rated for 100 amps and 600 volts with thermal magnetic trip technology.This 3 pole unit features a 65kA interrupt rating at 480V, unit mount lug connections, and is suitable for motor circuit protection with long-time and instantaneous trip functions.

• Manufacturer: Square D
• Part Number: HJL36100M73SK
• Amperage: 100 A
• Voltage Rating: 600 V AC
• Poles: 3
• Frame Type: H-Frame (Powerpact H)
• Trip Unit: Thermal Magnetic
• Interrupt Rating: 65kA at 480V, 25kA at 600V, 100kA at 240V
• Mounting Type: Unit Mount Lug
• Connection Type: Line and Load Side Lugs
• Continuous Current Rating: 80%
• UL Listed (UL 489)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJL36100M73SK
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJL
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : I - Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Magnetic Only

Product Data

• UPC : 785901928010
• GTIN : 00785901928010
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
