HJL36030UA - Schneider Electric PowerPact H 30A 3-Pole 600VAC Circuit Breaker

HJL36030UA

HJL36030UA is a Schneider Electric PowerPact H molded case circuit breaker designed for industrial and commercial power distribution applications.

This three-pole thermal-magnetic circuit breaker features a 30-ampere rating at 600VAC with a 25kA interrupt capacity at 600V AC. The unit mount construction includes line and load side lug terminals compatible with AWG 14 through AWG 3/0 aluminum or copper conductors. The breaker operates at 80% continuous current rating and includes a magnetic hold current of 350A with magnetic tripping at 750A. It is suitable for reverse-fed applications and provides long-time and instantaneous trip functions.

• Amperage: 30A
• Voltage: 600VAC, 250VDC
• Poles: 3-Pole
• Frame Type: H-Frame
• Interrupt Rating: 100kA at 240VAC, 65kA at 480VAC, 25kA at 600VAC
• Trip Unit: Thermal-Magnetic
• Mounting: Unit Mount with Lugs
• Wire Gauge: AWG 14 to AWG 3/0
• Continuous Rating: 80%
• Certifications: UL 489, CSA, NEMA, IEC, CE marked

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJL36030UA
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJL
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Weight : 5
