HJL26150 - Square D 150 Amp 600V 2 Pole Thermal Magnetic Circuit Breaker PowerPact H Frame

HJL26150

HJL26150 is a Square D 2 Pole thermal magnetic molded case circuit breaker rated for 150 Amps and 600VAC/250VDC operation.This circuit breaker features a PowerPact H series frame with a 25kA interrupting rating at 600VAC and 65kA at 480VAC. It supports unit and panel mounting types and includes long time and instantaneous trip functions for reliable circuit protection. The breaker uses line and load side lug connections compatible with AWG 14 to AWG 3/0 aluminum or copper wire. It is certified to multiple standards including UL, CSA, CE, IEC, and NEMA.

• Amperage: 150 Amps
• Voltage: 600VAC, 250VDC
• Poles: 2
• Frame Type: PowerPact H (HJL)
• Interrupt Rating: 25kAIC at 600VAC, 65kAIC at 480VAC
• Mounting Type: Unit, Panel
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
• Connection Type: Line and Load Side Lug
• Wire Gauge: AWG 14 to AWG 3/0 Aluminum/Copper
• Certifications: UL, CSA, CE, IEC, NEMA, NOM, EN, NMX, CCC
• Temperature Rating: -25 to 70 °C
• Color: Black

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJL26150
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 150
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901706687
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.05
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
