HJD3070W - Eaton Series C 70A 600VAC 3-Pole Molded Case Circuit Breaker

HJD3070W

HJD3070W is an Eaton Series C complete molded case circuit breaker designed for reliable power distribution and circuit protection in commercial and industrial applications. This three-pole breaker features fixed thermal and fixed magnetic trip protection with a J-frame configuration, delivering consistent performance across 50/60 Hz systems. The unit is rated for 70 amperes at 600 VAC or 250 VDC, with an interrupt rating of 100 kAIC at 240 VAC and 65 kAIC at 480 VAC, ensuring dependable fault protection. The bolt-on connection type allows for straightforward installation in standard panelboards and distribution equipment.

• Amperage Rating: 70A
• Voltage Rating: 600 VAC, 250 VDC
• Number of Poles: Three-pole
• Series: Eaton Series C
• Frame Type: J-frame
• Trip Type: Fixed thermal, fixed magnetic
• Interrupt Rating: 100 kAIC at 240 VAC, 65 kAIC at 480 VAC, 25 kAIC at 600 VAC
• Frequency Rating: 50/60 Hz
• Connection Type: Bolt-on
• Certifications: UL Listed
• Product Weight: 12.5 lb
• Warranty: One year from installation or eighteen months from shipment, whichever occurs first

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: HJD3070W
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HJD
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 782114983881
• GTIN : 00782114983881
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 10 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 12.5
• Certification : UL Listed
