JT3070T - Cutler Hammer 70 Amp 600VAC 3-Pole Thermal Magnetic Trip Unit JT Frame

JT3070T

JT3070T is a Cutler Hammer thermal magnetic trip unit designed for JT frame molded case circuit breakers.

This Eaton Cutler Hammer JT3070T trip unit features a 70 ampere rating, 600 VAC voltage rating, and 3 poles. It is a bolt-on mounting type with fixed thermal and adjustable magnetic trip settings, providing reliable protection for electrical circuits. This trip unit is UL and CSA approved, compatible with JT series circuit breakers, and designed for panel mounting.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Part Number: JT3070T
• Amperage: 70 Amps
• Voltage: 600 VAC
• Poles: 3
• Frame/Series: JT
• Trip Type: Thermal Magnetic (Fixed Thermal, Adjustable Magnetic)
• Mounting Type: Bolt-On
• Approvals: UL Listed, CSA Certified
• Weight: Approximately 1.35 lbs
• Dimensions (HxWxD): 5.3" x 4.3" x 6.9"

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JT3070T
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : Series C
• Type : C
• Voltage : 600VAC
• Amperage : 70
• Phase : 3
• Poles : 3
• Functions : Long Time and Instantaneous Trip
• Amperage Maximum : 70
• Amperage Minimum : 70
• Protection : Thermal Magnetic
• Compatible Frames : HJDDC,JD,HJD,JDC

Product Data

• UPC : 786679404096
• GTIN : 00786679404096
• Country of Origin : Dominican Republic
• Dimensions : 6.9 in x 5.3 in x 4.3 in (Length/Depth x Height x Width)
• Weight : 1.35
• Certification : UL
