HJD2175 - Eaton Series C Molded Case Circuit Breaker 175A 600VAC 2-Pole

HJD2175

HJD2175 is an Eaton Series C molded case circuit breaker designed for industrial and commercial power distribution applications requiring reliable overcurrent protection.

The HJD2175 features a J-frame design with fixed thermal and fixed magnetic trip units, delivering consistent performance across standard electrical systems. This two-pole breaker is rated for 600 VAC / 250 VDC operation and handles 175 amperes of continuous current. The breaker provides an interrupt rating of 100 kA at 240 VAC and 65 kA at 480 VAC, making it suitable for demanding load protection scenarios. Aluminum construction with line and load terminals supports both 50/60 Hz applications.

• Amperage: 175 A
• Voltage: 600 VAC / 250 VDC
• Poles: 2
• Series: C
• Frame: J-Frame (HJD)
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Interrupt Rating: 100 kA @ 240 VAC, 65 kA @ 480 VAC
• Frequency: 50/60 Hz
• Material: Aluminum
• Terminal Configuration: Line and Load

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJD2175
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HJD
• Voltage : 600
• Amperage : 175
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679031056
• GTIN : 00786679031056
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 11.25
• Certification : UL Listed
