HJD2150 - Eaton Series C J-Frame Molded Case Circuit Breaker, 2 Pole, 150A, 600VAC, 65kAIC, Fixed Thermal/Magnetic Trip, UL/CSA/CE

HJD2150

HJD2150 is a complete Eaton Series C J-Frame molded case circuit breaker designed for reliable protection in industrial power distribution applications.

This two-pole breaker features a 150A current rating, 600VAC maximum voltage, and a robust 65kA interrupting capacity at 480VAC (100kA at 240VAC). It is equipped with a fixed thermal and fixed magnetic trip unit for precise overcurrent protection. The HJD2150 is UL, CSA, and CE certified, ensuring compliance with North American and international standards. The breaker is supplied as a complete unit with frame, trip unit, and lugs, ready for installation.

Key Specifications
• Manufacturer: Eaton (Cutler-Hammer)
• Part Number: HJD2150
• Series/Frame: C Series, J-Frame
• Amperage: 150A
• Voltage: 600VAC, 250VDC
• Poles: 2
• Mounting Type: Fixed (Molded Case)
• Interrupt Rating: 65kAIC @ 480VAC, 100kAIC @ 240VAC
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Certifications: UL, CSA, CE
• Neutral Pole: No
• Shunt Trip: Optional
• Undervoltage Release: Optional

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJD2150
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HJD
• Voltage : 600
• Amperage : 150
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679117750
• GTIN : 00786679117750
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 11.25
• Certification : UL Listed
