HJD2100 - Eaton Series C J-Frame 2-Pole 100 Amp 600V Molded Case Circuit Breaker

HJD2100

HJD2100 is an Eaton Series C J-frame molded case circuit breaker designed for industrial and commercial power distribution applications. This two-pole breaker features fixed thermal and fixed magnetic trip units with a 100 ampere rating at 600 volts AC maximum, supporting 250 volts DC operation. The breaker incorporates a patented contact design with high-speed blow-open action for superior performance and reliability. Key Specifications

• Manufacturer: Eaton
• Part Number: HJD2100
• Amperage: 100 Amp
• Poles: 2
• Voltage Rating: 600 VAC / 250 VDC
• Frame Type: J-Frame (JD)
• Series: C
• Trip Type: Fixed Thermal / Fixed Magnetic
• Interrupt Rating: 100 kAIC at 240 VAC, 65 kAIC at 480 VAC, 25 kAIC at 600 VAC
• Connection Type: Feed-Thru
• Frequency: 50/60 Hz
• Certification: UL Approved

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJD2100
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HJD
• Voltage : 600
• Amperage : 100
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679107164
• GTIN : 00786679107164
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 10 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 11.25
• Certification : UL Listed
