HJA36150SR - Square D Powerpact H Molded Case Circuit Breaker 150A 600V 3 Pole I-Line Plug-In Thermal Magnetic

HJA36150SR

HJA36150SR is a Square D Powerpact H molded case circuit breaker designed for reliable power distribution protection.This 3 pole circuit breaker features a 150 ampere rating and operates at 600 volts AC. It uses a thermal magnetic trip unit with LI (long-time and instantaneous) trip functions for precise overload and short-circuit protection. The breaker has an I-Line style plug-in mounting and connection, suitable for reverse fed applications. It offers a high interrupting rating of up to 100kA at 240VAC and 65kA at 480VAC, with a continuous current rating of 80%. The breaker is UL listed and meets multiple certifications including CE, CSA, NEMA, NOM, and IEC. It is part of the H-frame series and supports wire sizes from AWG 14 to 3/0 aluminum or copper.

Key Specifications
• Amperage: 150 A
• Voltage: 600 VAC / 690 VAC / 250 VDC
• Poles: 3
• Mounting Type: I-Line plug-in bracket
• Interrupt Rating: 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC, 20 kA at 250 VDC
• Frame Type: H-Frame
• Trip Unit: Thermal Magnetic with LI functions
• Continuous Current Rating: 80%
• Connection: I-Line style plug-in
• Certifications: UL, CE, CSA, NEMA, NOM, IEC
• Wire Range: AWG 14 to 3/0 aluminum/copper

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 125Vdc shunt trip

Specifications

• Part Number: HJA36150SR
• Manufacturer : Square D
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Weight : 5
