Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
HJA36050SA
HJA36050SA is a 3-pole, 50A, 600V molded case circuit breaker designed for reliable power distribution in commercial and industrial applications. This Square D PowerPact H breaker features a thermal-magnetic trip unit and is compatible with I-Line panelboards and switchboards. The HJA36050SA is engineered for use in demanding environments, offering robust protection with a 65kA interrupt rating at 480V. It is suitable for installation in systems requiring UL and CSA certification, ensuring compliance with North American safety standards.
- Part Number: HJA36050SA
- Manufacturer: Square D
- Amperage: 50A
- Voltage: 600V
- Poles: 3
- Interrupt Rating: 65kA @ 480V
- Mounting Type: I-Line
- Series/Frame: PowerPact H
- Trip Unit: Thermal-Magnetic
- UL Listed
- CSA Certified
- Application: Power Distribution
Additional Information
complete with 120V shunt trip
Specifications
- Part Number: HJA36050SA
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 600
- Amperage : 50
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : I-Line Style Plug-In
- Functions : LI - Long-Time and Instantaneous
- Temp Rating : 28-158 °F (-2-70 °C)
- Protection : Thermal Magnetic
Product Data
- Dimensions : Height 6.42 in (163 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 5
- Wire Size : AWG 14...AWG 3/0 aluminum/copper terminal
