HJA36030YP - Square D PowerPact H 30A 3-Pole 600VAC Molded Case Circuit Breaker Thermal Magnetic I-Line

HJA36030YP

HJA36030YP is a Square D PowerPact H molded case circuit breaker designed for reliable protection in industrial and commercial electrical systems.This 30 amp, 3-pole circuit breaker operates at 600 volts AC with a 25kA interrupt rating. It features a thermal magnetic trip unit and an 80% rated I-Line design with a padlock handle for enhanced safety. The breaker is compatible with I-Line load and line lug connections and is certified by UL, CSA, CCC, and CE standards. Its frame size is H, and it supports mounting in standard PowerPact H panels.

• Amperage: 30 A
• Voltage Rating: 600 VAC
• Number of Poles: 3
• Interrupt Rating: 25 kA
• Frame: PowerPact H
• Trip Unit: Thermal Magnetic
• Mounting Type: I-Line
• Handle: Padlockable
• Certifications: UL, CSA, CCC, CE
• Dimensions: 4.48 in W x 4.8 in D x 9.73 in H
• Frequency: 50/60 Hz
• Compatible with ABC phase wiring

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA36030YP
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901950387
• GTIN : 00785901950387
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 6.867
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
