HJA260704 - Square D 70 Amp 600 Volt 2 Pole I-Line Style Molded Case Circuit Breaker

HJA260704

HJA260704 is a 2 pole, 70 amp, 600 volt I-Line style molded case circuit breaker from Square D designed for reliable circuit protection.This Square D HJA260704 circuit breaker features a thermal magnetic trip unit with current limiting capability, suitable for use in Class 611/612 I-Line panelboards and switchboards. It offers a high interrupting rating of 65kA at 480V AC and 100kA at 240V AC, ensuring robust protection for electrical distribution systems. The breaker is UL, CSA, and CE certified and supports single-phase applications.

Key Specifications
• Amperage: 70 Amps
• Voltage Rating: 600 Volts AC
• Poles: 2
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 65kA @ 480V, 100kA @ 240V
• Trip Unit: Thermal Magnetic, Current Limiting
• Series/Frame: HJA Powerpact
• Phase: Single Phase
• Certifications: UL, CSA, CE
• Application: Panelboard and Switchboard Use

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA260704
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 70
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901795766
• GTIN : 00785901795766
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
