HJA260404 - Square D 40A 600V 2 Pole I-Line Style Circuit Breaker PowerPact H Frame

HJA260404

HJA260404 is a Square D 2 pole, 40 amp, 600 volt I-Line style circuit breaker from the PowerPact H frame series.

This thermal magnetic circuit breaker features a 25kA interrupting rating at 600VAC and is designed for reliable protection in industrial and commercial electrical systems. It includes a thermal magnetic trip unit and is UL 489 listed with CSA, CE, and other international certifications. The breaker is suitable for panelboard and switchboard applications with a plug-in I-Line mounting style.

Key Specifications
• Amperage: 40A
• Voltage: 600V AC
• Poles: 2
• Interrupt Rating: 25kA at 600VAC
• Frame/Series: PowerPact H
• Trip Unit: Thermal Magnetic
• Mounting Type: I-Line Plug-In
• Certifications: UL 489, CSA, CE, NEMA, IEC
• Continuous Current Rating: 80%
• Phase: Single-phase (B & C phase)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA260404
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 40
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901539971
• GTIN : 00785901539971
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
