HJA260201 - Square D PowerPact HJA Molded Case Circuit Breaker, 20A, 2 Pole, 600V, I-Line, 25kA Interrupt, Thermal Magnetic Trip, UL 489, CSA, IEC

HJA260201

HJA260201 is a Square D PowerPact HJA series molded case circuit breaker designed for robust electrical protection in industrial and commercial applications.

This 2-pole, 20A breaker features an I-Line plug-in mounting style, a 600V AC voltage rating, and a thermal magnetic trip unit with fixed thermal and adjustable magnetic settings. It is certified to UL 489, CSA, and IEC standards, ensuring compliance and safety for power distribution systems.

Key Specifications
• Amperage: 20A
• Voltage: 600V AC, 250V DC
• Poles: 2
• Mounting Type: I-Line plug-in
• Interrupt Rating: 25kA @ 600V AC, 65kA @ 480V AC, 100kA @ 240V AC
• Series/Frame: PowerPact HJA
• Trip Unit: Thermal magnetic (fixed thermal, adjustable magnetic)
• Certifications: UL 489, CSA, IEC
• Connection: Phase AB
• Wire Size: 14 - 3/0 AWG
• Application: Power distribution
• Used On: Class 612 I-Line panelboards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA260201
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901442172
• GTIN : 00785901442172
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.41
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
