HGM36150 - Square D 150 Amp 600V 3 Pole PowerPact H Frame Molded Case Circuit Breaker, 35kA Interrupt, UL Listed

HGM36150

HGM36150 is a Square D PowerPact H Frame molded case circuit breaker designed for reliable circuit protection in demanding applications.

This 3-pole, 150 amp breaker operates at up to 600V AC and features a 35kA interrupt rating at 480V. It is unit mounted, suitable for a wide range of industrial and commercial uses, and is UL 489 listed for safety and compliance.

Key Specifications
• Part Number: HGM36150
• Manufacturer: Square D (Schneider Electric)
• Amperage: 150A
• Voltage: 600V AC
• Poles: 3
• Mounting Type: Unit Mount
• Interrupt Rating: 35kA at 480V
• Series/Frame: PowerPact H Frame
• Trip Unit: Thermal-Magnetic
• Certifications: UL 489 Listed
• Connection: Lug
• Operating Temperature: Up to 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGM36150
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGM
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901466826
• GTIN : 00785901466826
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
