HGL26035 - Square D 35 Amp 600 Volt 2 Pole H Frame Molded Case Circuit Breaker

HGL26035

HGL26035 is a Square D 35 Amp, 600 Volt, 2 Pole H Frame molded case circuit breaker designed for reliable circuit protection.This thermal magnetic circuit breaker features a unit mount design and a G interrupt rating, suitable for up to 600 VAC or 500 VDC applications. It is UL 489 listed and offers interrupt ratings of 65 kA at 240 V, 35 kA at 480 V, and 18 kA at 600 V, ensuring high performance and safety in demanding electrical environments.

• Amperage: 35 Amp
• Voltage Rating: 600 VAC / 500 VDC
• Poles: 2
• Frame Type: H Frame
• Mounting Type: Unit Mount
• Interrupt Rating: G Interrupt Code
• Interrupt Capacity: 65 kA @ 240 V, 35 kA @ 480 V, 18 kA @ 600 V
• Trip Unit: Thermal Magnetic
• UL Listing: UL 489
• Manufacturer: Square D (Schneider Electric)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGL26035
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGL
• Voltage : 600
• Amperage : 35
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901433804
• GTIN : 00785901433804
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.04
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
