HGF36015 - Square D PowerPacT H 15A 3-Pole 600V Thermal Magnetic Circuit Breaker

HGF36015

HGF36015 is a 3-pole, 600VAC molded case circuit breaker manufactured by Square D as part of the PowerPacT H-Frame series.

This thermal magnetic circuit breaker delivers reliable protection with an 18kA breaking capacity at 600VAC. The HGF36015 features a bolt-on mounting configuration with line and load side lug terminals, making it suitable for distribution applications. It is UL listed and designed for standard industrial and commercial power distribution systems.

• Manufacturer: Square D (Schneider Electric)
• Part Number: HGF36015
• Amperage: 15A
• Voltage: 600VAC
• Poles: 3
• Frame Type: H-Frame
• Trip Unit: Thermal Magnetic
• Breaking Capacity: 18kA at 600VAC
• Mounting: Bolt-On with Lugs
• Series: PowerPacT H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: HGF36015
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGF
• Voltage : 600
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• GTIN : 03606481244963
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
