HGA36150U33X - Square D 150A 600V 3 Pole PowerPacT H Circuit Breaker with Micrologic 3.2S Trip Unit

HGA36150U33X

HGA36150U33X is a Square D PowerPacT H molded case circuit breaker rated for 150 amps, 600 volts AC, and 3 poles, featuring a Micrologic 3.2S trip unit.This circuit breaker offers reliable protection with an interrupt rating of 18kA at 600VAC and 35kA at 480V, designed for I-Line style plug-in mounting. It is suitable for three-phase power distribution systems and complies with industry standards for safety and performance.

• Amperage: 150A
• Voltage Rating: 600VAC (up to 690VAC max)
• Poles: 3
• Interrupt Rating: 18kA at 600VAC, 35kA at 480VAC
• Frame/Series: PowerPacT H
• Trip Unit: Micrologic 3.2S
• Mounting Type: I-Line Style Plug-In
• Compatible with three-phase systems
• Certifications: Meets industry safety standards
• Manufacturer: Square D (Schneider Electric)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGA36150U33X
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGA
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Solid State
• Phase Connection : ABC

Product Data

• UPC : 078590194771
• GTIN : 00785901947714
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 6.382
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
