HGA36100U33X - Square D PowerPact H 100A 3-Pole 600V Circuit Breaker with Micrologic 3.2S Trip Unit

HGA36100U33X

HGA36100U33X is a Square D PowerPact H series circuit breaker rated for 100 amps and 600 volts AC, featuring a 3-pole I-Line mounting style and an electronic Micrologic 3.2S trip unit.This molded case circuit breaker offers a breaking capacity of 65 kA at 240 V AC, 35 kA at 480 V AC, and 18 kA at 600 V AC, with an 80% continuous current rating. It supports I-Line plug-in connection and is suitable for three-phase ABC systems. The breaker is UL listed, IEC and CE certified, and designed for reliable protection in industrial and commercial applications.

• Amperage: 100 A
• Voltage: 600 V AC
• Number of Poles: 3P
• Mounting Type: I-Line plug-in
• Interrupt Rating: 65 kA @ 240 V, 35 kA @ 480 V, 18 kA @ 600 V
• Series/Frame: PowerPact H
• Trip Unit: Electronic Micrologic 3.2S LSI
• Continuous Current Rating: 80%
• Wire Gauge: AWG 14 to AWG 3/0 (Al/Cu)
• Certifications: UL Listed, IEC, CE
• Phase: 3 (ABC)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGA36100U33X
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGA
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Solid State
• Phase Connection : ABC

Product Data

• UPC : 078590194767
• GTIN : 00785901947677
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 8.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
