HGA36100SA - Square D PowerPact H I-Line 100A 3-Pole 600V Thermal Magnetic Circuit Breaker with Shunt Trip

HGA36100SA

HGA36100SA is a Square D PowerPact H I-Line molded case circuit breaker rated for 100 amps, 3 poles, and 600 volts AC with thermal magnetic trip and shunt trip feature.This circuit breaker is designed for use in panelboards and switchboards, providing reliable current limiting and thermal magnetic protection. It features a 600V AC and 250V DC voltage rating, 18kA interrupt rating at 600V, and is UL, CSA, CE certified. The breaker is suitable for distribution applications and includes I-Line mounting for easy installation.

• Amperage: 100A
• Voltage Rating: 600V AC, 250V DC
• Poles: 3
• Mounting Type: I-Line
• Interrupt Rating: 18kA at 600V AC
• Series/Frame: PowerPact H
• Trip Unit: Thermal Magnetic with Shunt Trip
• Certifications: UL, CSA, CE
• Type: Molded Case Circuit Breaker
• Application: Panelboard and Switchboard

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120Vac shunt trip

Specifications

• Part Number: HGA36100SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901840787
• GTIN : 785901840787
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
