Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD4030
HFD4030 - Eaton Series C F-frame molded case circuit breaker with fixed thermal-fixed magnetic trip, rated at 30A and 600VAC.This complete four-pole breaker features HFD design, 100 kAIC interrupt rating at 240VAC and 65 kAIC at 480VAC, 250 VDC rating, load side terminals, and 50/60 Hz frequency for reliable overcurrent protection in electrical panels and assemblies.
- Part Number: HFD4030
- Manufacturer: Eaton
- Amperage Rating: 30A
- Voltage Rating: 600VAC, 250VDC
- Poles: Four-pole
- Frame: F-frame
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 100 kAIC at 240VAC, 65 kAIC at 480VAC
- Frequency: 50/60 Hz
- Circuit Breaker Type: Complete molded case
- Terminals: Load side
Specifications
- Part Number: HFD4030
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 30
- Phase : 3
- Poles : 4
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679253656
- GTIN : 00786679253656
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 5.25 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
