Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD4015
HFD4015 is a 15 Amp, 4-pole molded case circuit breaker from Eaton's C Series designed for reliable circuit protection.This Eaton HFD4015 breaker features a fixed thermal and fixed magnetic trip unit, suitable for use in 600 VAC and 250 VDC applications. It belongs to the F-frame C Series line, providing robust interrupt ratings up to 65 kA at 480 VAC and 100 kA at 240 VAC, ensuring high fault current interruption capability.
- Key Specifications
- Amperage: 15 A
- Voltage Rating: 600 VAC / 250 VDC
- Poles: 4
- Series/Frame: Eaton C Series, F-frame
- Trip Type: Fixed Thermal / Fixed Magnetic
- Interrupt Rating: 65 kA @ 480 VAC, 100 kA @ 240 VAC
- Part Number: HFD4015
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 15
- Phase : 3
- Poles : 4
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
- UPC : 786679253502
- GTIN : 00786679253502
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
