Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD4015L
HFD4015L is an Eaton Series C complete molded case circuit breaker designed for AC and DC power distribution systems with fixed thermal and fixed magnetic trip protection.
This F-frame breaker features a four-pole configuration rated for 15 amperes at 600 Vac or 250 Vdc. The breaker incorporates patented contact design with high-speed blow-open action for superior performance and reliability. It is suitable for panel mounting in industrial and commercial applications and meets UL 489 certification standards.
- Amperage Rating: 15 A
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: Four-pole
- Frame Type: F-frame
- Trip Type: Fixed Thermal, Fixed Magnetic (T186)
- Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
- Terminals: Line and load
- Frequency: 50/60 Hz
- Certifications: UL 489
- Product Weight: 6.3 lb
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: HFD4015L
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 15
- Phase : 3
- Poles : 4
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679271308
- GTIN : 00786679271308
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
