HFD1030BP10 - Eaton 30A 347VAC 1-Pole Series C Complete Molded Case Circuit Breaker F-Frame Fixed Thermal Magnetic Trip

HFD1030BP10

HFD1030BP10 is an Eaton Series C complete molded case circuit breaker designed for reliable circuit protection.This breaker features a fixed thermal and fixed magnetic trip type, with a single-pole configuration and a 30 ampere rating. It supports a maximum voltage of 347 VAC and 125 VDC, suitable for load side applications at 50/60 Hz frequency. The breaker is built on the F-frame Series C complete platform, offering interrupt ratings of 100 kAIC at 240 VAC and 65 kAIC at 480 VAC, ensuring high fault current interruption capability.

Key Specifications
• Amperage: 30 Amp
• Voltage Rating: 347 VAC, 125 VDC
• Poles: Single Pole
• Frame/Series: Eaton Series C Complete, F-Frame
• Trip Type: Fixed Thermal, Fixed Magnetic
• Interrupt Rating: 100 kAIC at 240 VAC, 65 kAIC at 480 VAC
• Mounting Type: Load Side
• Frequency: 50/60 Hz
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HFD1030BP10
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HFD
• Voltage : 277 AC
• Amperage : 30
• Phase : 1
• Poles : 1
• AIC rating : 65kA@277V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 786679048276
• GTIN : 00786679048276
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 1.5
• Certification : UL Listed
