Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
HFD1030L
HFD1030L is a Cutler Hammer Series C molded case circuit breaker rated for 30 amps and 347 volts with 1 pole configuration.This thermal magnetic circuit breaker features a fixed thermal/magnetic trip unit, bolt-on mounting, and a high interrupt rating of 65kA at 480 VAC. It is designed for reliable protection in electrical distribution systems and is UL listed for safety compliance.
- Amperage: 30 Amps
- Voltage Rating: 347 VAC / 125 VDC
- Poles: 1
- Mounting Type: Bolt-On
- Interrupt Rating: 65kA at 480 VAC, 100kA at 240 VAC
- Series/Frame: Series C, Type HFD
- Trip Unit: Fixed Thermal/Magnetic
- Certifications: UL Listed
- Connection: Feed-Thru
- Phase: Single Phase
Specifications
- Part Number: HFD1030L
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 277 AC
- Amperage : 30
- Phase : 1
- Poles : 1
- AIC rating : 65kA@277V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous Trip
- Frame Size : F Frame
- Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679175521
- GTIN : 00786679175521
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
