HDL36060C - Square D PowerPact H 60A 3-Pole 600VAC Molded Case Circuit Breaker

HDL36060C

HDL36060C is a 3-pole, 60-amp molded case circuit breaker rated for 600VAC or 250VDC operation, manufactured by Square D (Schneider Electric). HDL36060C is designed for unit mount applications with thermal-magnetic tripping and current-limiting protection to safeguard electrical systems from overloads and short circuits. This PowerPact H-frame breaker features a 100% continuous current rating and is UL 489 listed for reliable performance in industrial and commercial power distribution.

• Amperage: 60A
• Voltage: 600VAC / 250VDC
• Poles: 3
• Frame: H-Frame (150A frame)
• Interrupt Rating: 14kA at 600VAC
• Trip Unit: Thermal-Magnetic
• Mounting: Unit Mount
• Continuous Current Rating: 100%
• Tripping Mechanism: Thermal-Magnetic, Current Limiting
• Certification: UL 489 Listed
• Dimensions: 4.36 in L x 4.12 in W x 6.4 in H
• Wire Size: 14-3/0 AWG

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDL36060C
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDL
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901634577
• GTIN : 00785901634577
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
