Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
HDL36030AASA
HDL36030AASA is a PowerPact H-Frame molded case circuit breaker designed for reliable thermal-magnetic protection in commercial and industrial applications. This 30A, 3-pole breaker is rated for up to 600V AC and features a 14kA interrupt rating at 600V, making it suitable for demanding environments. It is unit mount and comes with lugs for both line and load connections, supporting wire gauges from AWG 14 to AWG 3/0 copper or aluminum. The breaker is UL 489 listed and meets all relevant safety standards for circuit protection. The HDL36030AASA is part of the PowerPact H series, known for durability and consistent performance. Its thermal-magnetic trip unit provides both overload and short-circuit protection, ensuring safe operation in a wide range of electrical systems. The breaker is designed for easy installation and maintenance, with a compact footprint and robust construction.
- Part Number: HDL36030AASA
- Manufacturer: Schneider Electric
- Series/Frame: PowerPact H
- Amperage: 30A
- Poles: 3
- Voltage: 600V AC
- Interrupt Rating: 14kA at 600V AC
- Mounting Type: Unit mount
- Trip Unit: Thermal-magnetic
- Electrical Connection: Lugs (line and load)
- Wire Gauge: AWG 14 to AWG 3/0 (copper/aluminum)
- Certifications: UL 489 listed
Additional Information
complete with 1A/1B auxiliary switch and 110/130Vac shunt trip
Specifications
- Part Number: HDL36030AASA
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 600
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Country of Origin : United States
- Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
- Weight : 4.9
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
