HDL26045 - Square D 45 Amp 600V 2 Pole Powerpact H Frame Circuit Breaker Thermal Magnetic

HDL26045

HDL26045 is a 2 pole, 45 amp, 600 VAC/250 VDC thermal magnetic molded case circuit breaker from Square D's Powerpact H series.HDL26045 features unit mounting, long time and instantaneous trip functions, and a D interrupt rating with 25 kA at 240 VAC, 18 kA at 480 VAC, 14 kA at 600 VAC, and 20 kA at 250 VDC. It is UL 489, CSA, IEC, CE, and NOM certified, designed for reliable overload and short circuit protection with lug-type line and load terminals.

Key Specifications
• Amperage: 45 Amp
• Voltage: 600 VAC / 250 VDC
• Poles: 2
• Mounting Type: Unit Mount
• Interrupt Rating: 25 kA @ 240 VAC, 18 kA @ 480 VAC, 14 kA @ 600 VAC, 20 kA @ 250 VDC
• Series/Frame: Powerpact H Frame
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous
• Terminal Connection: Lug (Line and Load)
• Certifications: UL 489, CSA, IEC, CE, NOM
• Wire Gauge: AWG 14 to 3/0 Aluminum/Copper
• Dimensions (WxDxH): 2.74 x 4.36 x 6.4 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDL26045
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDL
• Voltage : 600
• Amperage : 45
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : H
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901630272
• GTIN : 00785901630272
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.04
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
